AKIRA ADJ

AKIRA series developed a series of lighting fixtures, specially designed to balance the direct and indirect lighting

Reflector electroplated with black nickel absorb the light to prevent the reflector from making secondary glare

Lighting source deeply hided, luminous range contraction, to ensure that people cannot see the light source directly in a certain visual range, and to reduce the direct glare

Lighting optical system consist with two reflector, present a reasonable light distribution

Description

WL111116 6W Ø65

Product CodeLEDPowerLumenInputCRIFinishBeam AngleCCTIP RatingTilt/RotateDimensionCutoutDownloads
WL111116.02.15.27COB6W300lm100-240VAC≥95WH15°2700KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.24.27COB6W300lm100-240VAC≥95WH24°2700KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.36.27COB6W300lm100-240VAC≥95WH36°2700KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.15.27COB6W300lm100-240VAC≥95BK15°2700KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.24.27COB6W300lm100-240VAC≥95BK24°2700KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.36.27COB6W300lm100-240VAC≥95BK36°2700KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.15.40COB6W315lm100-240VAC≥95WH15°4000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.24.40COB6W315lm100-240VAC≥95WH24°4000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.36.40COB6W315lm100-240VAC≥95WH36°4000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.15.40COB6W315lm100-240VAC≥95BK15°4000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.24.40COB6W315lm100-240VAC≥95BK24°4000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.36.40COB6W315lm100-240VAC≥95BK36°4000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.15.50COB6W330lm100-240VAC≥95WH15°5000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.24.50COB6W330lm100-240VAC≥95WH24°5000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.02.36.50COB6W330lm100-240VAC≥95WH36°5000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.15.50COB6W330lm100-240VAC≥95BK15°5000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.24.50COB6W330lm100-240VAC≥95BK24°5000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue
WL111116.04.36.50COB6W330lm100-240VAC≥95BK36°5000KIP2030°/355°Ø65x75mmØ55mmDatasheet
IES File
Catalogue

WL111118 8W Ø85

Product CodeLEDPowerLumenInputCRIFinishBeam AngleCCTIP RatingTilt/RotateDimensionCutoutDownloads
WL111118.02.15.27COB8W366lm100-240VAC≥95WH15°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.24.27COB8W366lm100-240VAC≥95WH24°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.36.27COB8W366lm100-240VAC≥95WH36°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.15.27COB8W366lm100-240VAC≥95BK15°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.24.27COB8W366lm100-240VAC≥95BK24°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.36.27COB8W366lm100-240VAC≥95BK36°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.15.40COB8W384lm100-240VAC≥95WH15°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.24.40COB8W384lm100-240VAC≥95WH24°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.36.40COB8W384lm100-240VAC≥95WH36°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.15.40COB8W384lm100-240VAC≥95BK15°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.24.40COB8W384lm100-240VAC≥95BK24°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.36.40COB8W384lm100-240VAC≥95BK36°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.15.50COB8W403lm100-240VAC≥95WH15°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.24.50COB8W403lm100-240VAC≥95WH24°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.02.36.50COB8W403lm100-240VAC≥95WH36°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.15.50COB8W403lm100-240VAC≥95BK15°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.24.50COB8W403lm100-240VAC≥95BK24°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111118.04.36.50COB8W403lm100-240VAC≥95BK36°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue

WL111119 12W Ø85

Product CodeLEDPowerLumenInputCRIFinishBeam AngleCCTIP RatingTilt/RotateDimensionCutoutDownloads
WL111119.02.15.27COB12W576lm100-240VAC≥95WH15°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.24.27COB12W576lm100-240VAC≥95WH24°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.36.27COB12W576lm100-240VAC≥95WH36°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.15.27COB12W576lm100-240VAC≥95BK15°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.24.27COB12W576lm100-240VAC≥95BK24°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.36.27COB12W576lm100-240VAC≥95BK36°2700KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.15.40COB12W605lm100-240VAC≥95WH15°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.24.40COB12W605lm100-240VAC≥95WH24°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.36.40COB12W605lm100-240VAC≥95WH36°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.15.40COB12W605lm100-240VAC≥95BK15°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.24.40COB12W605lm100-240VAC≥95BK24°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.36.40COB12W605lm100-240VAC≥95BK36°4000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.15.50COB12W635lm100-240VAC≥95WH15°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.24.50COB12W635lm100-240VAC≥95WH24°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.02.36.50COB12W635lm100-240VAC≥95WH36°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.15.50COB12W635lm100-240VAC≥95BK15°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.24.50COB12W635lm100-240VAC≥95BK24°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue
WL111119.04.36.50COB12W635lm100-240VAC≥95BK36°5000KIP2030°/355°Ø85x110mmØ75mmDatasheet
IES File
Catalogue

WL111129 8W Ø114

Product CodeLEDPowerLumenInputCRIFinishBeam AngleCCTIP RatingTilt/RotateDimensionCutoutDownloads
WL111129.02.15.27COB8W366lm100-240VAC≥95WH15°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.24.27COB8W366lm100-240VAC≥95WH24°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.36.27COB8W366lm100-240VAC≥95WH36°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.15.27COB8W366lm100-240VAC≥95BK15°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.24.27COB8W366lm100-240VAC≥95BK24°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.36.27COB8W366lm100-240VAC≥95BK36°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.15.40COB8W384lm100-240VAC≥95WH15°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.24.40COB8W384lm100-240VAC≥95WH24°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.36.40COB8W384lm100-240VAC≥95WH36°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.15.40COB8W384lm100-240VAC≥95BK15°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.24.40COB8W384lm100-240VAC≥95BK24°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.36.40COB8W384lm100-240VAC≥95BK36°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.15.50COB8W403lm100-240VAC≥95WH15°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.24.50COB8W403lm100-240VAC≥95WH24°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.02.36.50COB8W403lm100-240VAC≥95WH36°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.15.50COB8W403lm100-240VAC≥95BK15°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.24.50COB8W403lm100-240VAC≥95BK24°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111129.04.36.50COB8W403lm100-240VAC≥95BK36°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue

WL111130 12W Ø114

Product CodeLEDPowerLumenInputCRIFinishBeam AngleCCTIP RatingTilt/RotateDimensionCutoutDownloads
WL111130.02.15.27COB12W576lm100-240VAC≥95WH15°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.24.27COB12W576lm100-240VAC≥95WH24°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.36.27COB12W576lm100-240VAC≥95WH36°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.15.27COB12W576lm100-240VAC≥95BK15°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.24.27COB12W576lm100-240VAC≥95BK24°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.36.27COB12W576lm100-240VAC≥95BK36°2700KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.15.40COB12W605lm100-240VAC≥95WH15°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.24.40COB12W605lm100-240VAC≥95WH24°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.36.40COB12W605lm100-240VAC≥95WH36°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.15.40COB12W605lm100-240VAC≥95BK15°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.24.40COB12W605lm100-240VAC≥95BK24°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.36.40COB12W605lm100-240VAC≥95BK36°4000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.15.50COB12W635lm100-240VAC≥95WH15°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.24.50COB12W635lm100-240VAC≥95WH24°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.02.36.50COB12W635lm100-240VAC≥95WH36°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.15.50COB12W635lm100-240VAC≥95BK15°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.24.50COB12W635lm100-240VAC≥95BK24°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
WL111130.04.36.50COB12W635lm100-240VAC≥95BK36°5000KIP2030°/355°Ø114x110mmØ80mmDatasheet
IES File
Catalogue
